Direct-current Power Supplies

PowerClass

DimMaster™PowerSupplies

Model Number Series	Model Series Description	Input Voltage	Input Current	Output Voltage DC	Output Current	Output Power
DMD50	Integrated LED Driver	100 – 240V~	0.6A	40V	1.0A – 0.25A	50W
DMD150	Integrated LED Driver 12 – 24Vdc Fan Supply Fan Failure Function 48VDc Aux Supply	100 – 230V~	1.5A	40V	3.1A – 1.0A	150W
DMD180	12 – 24Vdc Fan Supply	100 – 230V~	2.1A	48V	3.75A	180W
DM260	12 – 24Vdc Fan Supply Fan Failure Function Dual PWM Output	100 – 230V~	3A	47V,49V 52V,63V	5.5A,5.3A 5.0A,4.1A	260W
DM400	12 -24Vdc Fan Supply	100 – 230V~	4.6A	41V,45V	9.75A,8.9A	400W

Dual Output (Combo) Power Supplies

Model Number Series	Model Series Description	Input Voltage	Input Current	Output Voltage DC	Output Current	Output Power
PFC140	AC-DC Output Voltage Regulated	100 – 250V~	3.9A	380V 28V	0.4A 7.1A	200W power 140W PFC
PFC230	AC-DC Output Voltage Regulated	100 – 250V~	5.6A	390V 28V	0.6A 5.2A	170W power 230W PFC
PFC330	AC-DC Output Voltage Regulated	100 – 250V~	6.5A	380V 24 – 28V	0.9A 7.1 – 8.3A	330W PFC +200W LVS =530W Total
PFC505	AC-DC Output Voltage Regulated	100 – 240V~	8.3A	380V 24 – 48V	1.32A 8.3A	500W + 200W = 700W Total
PFC1080	AC-DC Output Voltage Regulated	100 – 250V~	12.7A	390V 28V	2.3A 7.1A	390Vdc = 881W + 28V = 200W = 1080W Total

Standard Power Supplies

Model Number Series	Model Series Description	Input Voltage	Input Current	Output Voltage DC	Output Current	Output Power
BMS40	Battery Backed PSU AC – DC, DC – DC Dual inputs AC and DC with built-in battery charger	100 – 240V~ 12Vdc	1A	12.5V	2.5A	40W
RBS40	AC – DC Output Voltage Regulated Linear “Strip” Design Daisy Chain Configurable	100 – 277V~	0.48A	48V,29.5V	0.8A – 1.4A	40W
PR70P	AC – DC Output Voltage Regulated	100 – 277V~	0.8A	48V,29.5V	1.5A,2.4A	70W
PR75	AC – DC Output Voltage Regulated	100 – 240V~	0.9A	36V,12V	2.1A,6.2A	75W
BBS100	Battery Backed PSU AC – DC, DC -DC Dual inputs AC and DC with built-in battery charger	90 – 264V, 20 – 60Vdc	2.5A,6A	24V,12V	4.2A,5A	100W
PR100	AC – DC Output Voltage Regulated	100 – 240V~	1.2A	42 – 48V	2.4A – 2.1A	100W
MP120	AC – DC Output Voltage Regulated	100 – 250V	1.8A	24V	5A	120W
LM150A	AC – DC Output Voltage Regulated	100 – 250V~	1.8A	48V	3.1A	150W
LM150P	AC – DC Output Voltage Regulated	100 – 277V~	2.4A	48V,12V	3.1A,12.5A	150W
PR150	AC – DC Output Voltage Regulated	100 – 240V~	0.8A	48V	3.1A	150W
LM200A	AC – DC Output Voltage Regulated	100 – 250V~	2.6A	48V,24V	4.2A,8.3A	200W
LM200P	AC – DC Output Voltage Regulated	100 – 277V~	2.6A	48V,28V, 24V	4.2A,7.1A, 8.3A	200W
PM200	DC – DC Power Module	360 – 400Vdc	0.6A	32V	6.25A	200W
MP250	AC – DC Output Voltage Regulated	100 – 240V~	4A	40V	3.75A,5A	250W
LE260	AC – DC Output Voltage Regulated	100 – 250V~	3.1A	48V,24V	5.4A,10.8A	260W
LH300	AC – DC Output Voltage Regulated	100 – 277V~	3.5A	36V	8.3A	300W
LS300	AC – DC Output Voltage Regulated	100 – 250V~	3.7A	36V	8.3A	300W
MP300	AC – DC Output Voltage Regulated	100 – 250V~	3.5A	24V	12.5A	300W
LK320	AC – DC Output Voltage Regulated	100 – 250V~	3.8A	390V	0.82A	320W PFC
PFC320	Lamp Driver Power Supply	100 – 250V~	3.6A	390V	0.82A	320W PFC
LK350	AC – DC Output Voltage Regulated	100 – 250V~	4.6A	27V	13A	350W
LR350	AC – DC Output Voltage Regulated	100 – 250V~	4.6A	52V,28V	6.7A, 12.5A	350W
LP355	AC – DC Output Voltage Regulated	100 – 250V~	4.1A	48V,24V	3A,5.7A	355W
LP400	AC – DC Output Voltage Regulated	100 – 250V~	4.9A	48 – 52V	8.3A – 7.7A	400W
LR400	AC – DC Output Voltage Regulated	100 – 250V~	4.6A	48V	8.3A	400W
LP550	AC – DC Output Voltage Regulated	100 – 240V~	8A	12V	45.8A	550W
LP600	AC – DC Output Voltage Regulated Integrated Fan	100 – 240V~	7.1A	48V	12.5A	600W
LP655	AC – DC Output Voltage Regulated Dual Output	100 – 250V~	8.0A	45 – 53V 24V	3A – 11A 3A	655W
